T100 Thermal Cycler

Description

Description

The T100 thermal cycler is a small thermal cycler offering a comprehensive set of convenient features in a small footprint. This compact thermal cycler features an intuitive touch-screen user interface to make running PCR easy. Thermal gradient technology allows you to quickly optimize your reaction in a single run. With its robust design, the T100 system is a reliable personal thermal cycler that delivers exceptional performance for years — Launch the System Tour to test drive the T100 thermal cycler now.

Features and Benefits of the T100 Thermal Cycler

  • Intuitive touch screeneasy programming using a large color touch screen and intuitive interface
  • Consistent results — robust design ensures effective and consistent performance run to run
  • Easy optimization — this gradient thermal cycler allows fast PCR optimization using a unique thermal gradient
  • Easy protocol management — protocols can be organized using personalized folders or a USB flash drive
  • Small space-saving footprint — the T100 is a compact thermal cycler that fits in any laboratory

BioRad T100 Thermal Cycler Users Around
the World

Life science researchers all over the world use the T100 thermal cycler in their daily routine. In this video, real-world users describe how it saves them time and helps them consistently obtain high-quality data, with high uniformity and reproducibility. The T100 thermal cycler is praised for being user-friendly, reliable, and enjoyable to use via the touch-screen interface.

Applications and Uses for the T100 Thermal Cycler

More Information

Specifications

Specifications

Thermal Cycler

Sample capacity
96 x 0.2 ml tubes, 0.2 ml tube strips, or 1 x 96-well plate
Maximum ramp rate, °C/sec
4
Average ramp rate, °C/sec
2.5
Temperature range
4–100°C
Temperature accuracy
±0.5°C of programmed target
Temperature uniformity
±0.5°C well-to-well within 30 sec of arrival at target temperature
Input power
100–150 VAC, 50–60 Hz; 220–240 VAC, 50–60 Hz; 700 W maximum
Display
5.7'' VGA color touch screen
Port
1 USB A
Memory
500 typical programs; unlimited with USB flash drive expansion
Dimensions (W x D x H)
26 x 47 x 23 cm (10 x 18 x 9'')
Weight
9 kg (20 lb)
Gradient

Gradient range
30–100°C
Temperature differential range
1–25°C

Ordering

Ordering

items

Use the filters below to refine results!

(Discontinued) T100 Thermal Cycler
1861096
Thermal cycler system, includes 96-well thermal cycler, power cord, tube support ring
1863000
Pkg of 2, optional clear plastic cover for the T100™ thermal cycler that shields the touch-screen surface from dust, reagents, and scratches
(Discontinued) Tube Support Ring
1862000
Pkg of 2, extra tube support ring for use with individual tubes in the T100™ thermal cycler

Kits & Reagents

Kits & Reagents

1708890
25 x 20 µl reactions, includes 5x reverse-transcription reaction mix, iScript reverse transcriptase, nuclease-free water
1708891
100 x 20 µl reactions, includes 5x reverse-transcription reaction mix, iScript reverse transcriptase, nuclease-free water
1708891BUN
500 x 20 µl reactions, includes 5x reverse-transcription reaction mix, iScript reverse transcriptase, nuclease-free water
1708896
25 x 20 µl reactions, includes 5x reaction mix, iScript reverse transcriptase, oligo(dT), random primer mix, gene-specific primer enhancer solution, nuclease-free water
1708897
100 x 20 µl reactions, includes 5x reaction mix, iScript reverse transcriptase, oligo(dT), random primer mix, gene-specific primer enhancer solution, nuclease-free water
1708897BUN
500 x 20 µl reactions, includes 5x reaction mix, iScript Reverse Transcriptase, oligo(dT), random primer mix, gene-specific primer enhancer solution, nuclease-free water
1708870
250 U (5 U/µl), hot-start polymerase for PCR and real-time PCR, includes 1.25 ml each 10x PCR buffer and 50 mM MgCl2
1708875
5,000 U (5 U/µl), hot-start polymerase for PCR and real-time PCR, includes 25 ml each 10x PCR buffer and 50 mM MgCl2
1708872
1.25 ml, 50 mM MgCl2 solution, for PCR applications
1708874
200 µl, premixed dNTP solution, 10 mM each (dATP, dCTP, dGTP, dTTP)
1725300
20 U, 2 U/µl, stand-alone enzyme, includes 5x reaction buffers, MgCl2 solution, DMSO
1725301
100 U, 2 U/µl, stand-alone enzyme, includes 5x reaction buffers, MgCl2 solution, DMSO
1725302
500 U, 2 U/µl, stand-alone enzyme, includes 5x reaction buffers, MgCl2 solution, DMSO
1725302BUN
5 x 500 U, 2 U/µl, stand-alone enzyme, includes 5x reaction buffers, MgCl2 solution, DMSO
1725310
100 x 50 µl reactions, premixed PCR reagents, includes 2x master mix (0.04 U/µl), DMSO; suitable for most templates
1725320
100 x 50 µl reactions, premixed PCR reagents, includes 2x master mix (0.04 U/µl), DMSO; suitable for GC-rich templates
1725330
50 U, 2 U/µl, iProof polymerase PCR kit includes 5x reaction buffers, MgCl2 solution, DMSO, dNTPs, λ DNA, 1.3 and 10 kb primers, DNA standard
1725331
200 U, 2 U/µl, iProof DNA polymerase PCR kit includes 5x reaction buffers, MgCl2 solution, DMSO, dNTPs, λ DNA, 1.3 and 10 kb primers, DNA standard

Gel Systems

Gel Systems

1704507
Horizontal high-throughput electrophoresis system, includes 25 x 25 cm UV-transparent tray, 26- and 51-well combs, gel caster
1704501
Horizontal high-throughput electrophoresis system, includes 25 x 15 cm UV-transparent tray, 26- and 51-well combs, gel caster
1704482
Horizontal electrophoresis system, includes 15- and 20-well combs, 15 x 15 cm (W x L) UV-transparent tray, casting gates, gel caster
1704484
Horizontal electrophoresis system, includes 15- and 20-well combs, 15 x 25 cm (W x L) UV-transparent tray, gel caster
1704468
Horizontal electrophoresis system, includes 15- and 20-well combs, 15 x 10 cm (W x L) UV-transparent tray
1704469
Horizontal electrophoresis system, includes 15- and 20-well combs, 15 x 10 cm (W x L) UV-transparent tray, mini-gel caster
1704466
Mini horizontal electrophoresis system, includes 8- and 15-well combs, 7 x 10 cm UV-transparent tray
1704467
Mini horizontal electrophoresis system, includes 8- and 15-well combs, 7 x 10 cm (W x L) UV-transparent tray, mini-gel caster

Plastics

Plastics

MLP9601
Pkg of 25, clear PCR plate, one-component polypropylene, can be cut for fewer samples
HSS9601
Pkg of 25, clear shell/clear well PCR plate to fit most instruments, rigid 2-component design
2239441
Pkg of 25, semi-skirted PCR plate for iCycler iQ®, iQ™5, MyiQ™, and MyiQ™2 Real-Time PCR Detection Systems
MSB1001
Pkg of 100, optically clear seal for PCR plates
MSA5001
Pkg of 50, nonadhesive sealing film for PCR plates and tubes
MSF1001
Pkg of 100, aluminized foil seal for PCR plates, pierceable
TBS0201
Pkg of 125, thin-wall polypropylene 8-tube strips for PCR, natural (1,000 tubes)
TBS1201
Pkg of 100, thin-wall polypropylene 12-tube strips for PCR, natural (1,200 tubes)
TCS0801
Pkg of 130, 8-cap strips for 0.2 ml tubes and plates for PCR, clear
TCS0803
Pkg of 120, 8-cap strips for 0.2 ml tubes and plates for PCR and optical reactions, ultraclear
TCS1201
Pkg of 200, 12-cap strips for 0.2 ml tubes and plates for PCR, clear
TFI0201
Pkg of 1,000, thin-wall polypropylene PCR tubes with attached caps for labeling, full-height wells, natural
TWI0201
Pkg of 1,000, thin-wall polypropylene PCR tubes with attached domed caps, full-height wells, natural

Download

Download

T100™ Firmware Upgrade
SOFT-T100-FW
Firmware files and instructions for the T100 thermal cycler. Version 1.201

Documents

Documents

Number Description Options
10020524
T100 Thermal Cycler Quick Guide, Rev B
10021426
Amplification Plastics and Reagents Selection Guide for the T100™ Thermal Cycler, Rev B
5277
Bio-Rad Thermal Cyclers Brochure, Rev G
[ Add to Cart (Free) ]
10000145577
T100 Thermal Cycler Instruction Manual
6777
Protocol for Single Cell Gene Expression Profiling by Multiplex RT-qPCR
6060
T100 Thermal Cycler Specifications Sheet
[ Add to Cart (Free) ]
LIT-6065
T100 Thermal Cycler Brochure, Rev C
[ Add to Cart (Free) ]
